Flood Protection Gabion Basket Construction With Heavily Zinc Galvanised Wire 60 x 80MM

प्रमाणन
अच्छी गुणवत्ता gabion जाली मशीन बिक्री के लिए
We got three machines form KONSON,the machine is good quality and they provide service of installation and debugging.

—— Hassan Fehmi from Turkey

I imported 80,000 sets gabion boxes.The products and marketing team are both excellent.The gabion got a good mark in quality test.

—— Soriane Morchedi from Algeria

मैं अब ऑनलाइन चैट कर रहा हूँ

Flood Protection Gabion Basket Construction With Heavily Zinc Galvanised Wire 60 x 80MM

चीन Flood Protection Gabion Basket Construction With Heavily Zinc Galvanised Wire 60 x 80MM आपूर्तिकर्ता

बड़ी छवि :  Flood Protection Gabion Basket Construction With Heavily Zinc Galvanised Wire 60 x 80MM

उत्पाद विवरण:

Place of Origin: Jiangsu, China
ब्रांड नाम: Konson
प्रमाणन: ISO9001,SGS,CE,ASTMA97597,EN 10223 standard.
Model Number: KS-Gabion

भुगतान & नौवहन नियमों:

Minimum Order Quantity: 1000 sqm
मूल्य: Discuss in mail
Packaging Details: weave bag,flat bundle,binding with steel strape or strands,some rolls.as your design.
Delivery Time: 15 days for 1x40 feet FCL
Payment Terms: L/C,T/T
Supply Ability: 12000 sqm per day
Contact Now
विस्तृत उत्पाद विवरण

Flood Protection Gabion Basket Construction With Heavily Zinc Galvanised Wire 60 x 80MM





Gabion Basket details:



Gabion basket consist of rectangular units, fabricated from a double twisted hexagonal mesh. Filled with stones, gabions become large, flexible and permeable elements from which a broad range of structures may be built. Gabions and mattresses are widely used for hydraulic and geo- technical control such as retaining walls, riverbank protections, weirs, channel linings etc.
Gabion baskets are divided into cells with diaphragms (usually spaced at 1 meter or 3’ intervals), whose function is to reinforce the structure. The mesh (except for the diaphragms) is reinforced on all edges with wires of a larger diameter to strengthen the gabions and facilitate the assembly and installation.





Engineering projects:



Gabion 3x1x1 is common in river construction, gabion box is filled with rock at the project  site to form flexible, permeable, monolithic structures such as retaining walls, channel linings  and weirs for erosion control projects.



Flood Protection Gabion Basket Construction With Heavily Zinc Galvanised Wire 60 x 80MM







Specification:



Standard sizes in mesh 80mm x 100mm nominal, wire diameter 2.7mm, Heavily zinc galvanised  wire or Galfan coated with a 95%Zinc + 5% Aluminium Alloy:



Specification of gabion baskets

Mesh size
(mm)

Body Wire Dia.(mm)

Wire (PVC wire )/Inner/Outside
 Dia.(mm)

Max Width (mm)

60X80

2.0-2.8

2.0/3.0-2.5/3.5

4300

80X100

2.0-3.2

2.0/3.0-2.8/3.8

4300

80X120

2.0-3.2

2.0/3.0-2.8/3.8

4300

100X120

2.0-3.4

2.0/3.0-2.8/3.8

4300

100X150

2.0-3.4

2.0/3.0-2.8/3.8

4300

120X150

2.0-4.0

2.0/3.0-3.0/4.0

4300





Applications:



Building blocks of gravity walls

Forming of gravity walls

Reinforced structure (a combination of reinforcing wire mesh containers)

Control and guide of water or flood

Flood bank or guiding bank

Preventing of rock breaking

Water and soil protection

Bridge protection

Strengthening structure of soil

Protection engineering of seaside area.
